SC/NC double function
dilation catheter for PTCA
Technological innovation
Allows to join 2 technologies in 1 (SC/NC)
Simplicity and versatility
It acts as SC or NC depending on the pressure applied to the ball.
Cost-Efficiency
The most cost efficient balloon on the market by reducing the use of balloons in a procedure.
| P(atm) | diameter (mm) | ||
| SC 1.25 | SC 1.50 | ||
| SC | 6 | 1.21 | 1.44 |
| 7 | 1.23 | 1.47 | |
| 8 | 1.25 | 1.50 | |
| 9 | 1.27 | 1.53 | |
| 10 | 1.29 | 1.56 | |
| eleven | 1.31 | 1.58 | |
| 12 | 1.34 | 1.61 | |
| 13 | 1.36 | 1.64 | |
| 14 | 1.38 | 1.67 | |
| fifteen | 1.40 | 1.69 | |
| 16 | 1.42 | 1.72 | |
| P(atm) | diameter (mm) | P(atm) | ||||||||
| SC 2.00 | SC 2.25 | SC 2.50 | SC 2.75 | SC 3.00 | SC 3.50 | SC 4.00 | ||||
| NA 2.25 | not 2.50 | NA 2.75 | NA 3.00 | NA 3.50 | NA 4.00 | NA 4.50 | ||||
| SC | 6 | 1.92 | 2.17 | 2.42 | 2.67 | 2.86 | 3.36 | 4.00 | 6 | SC |
| 7 | 1.96 | 2.21 | 2.46 | 2.71 | 2.93 | 3.43 | 4.08 | 7 | ||
| 8 | 2.00 | 2.25 | 2.50 | 2.75 | 3.00 | 3.50 | 4.17 | 8 | ||
| 9 | 2.04 | 2.29 | 2.54 | 2.79 | 3.08 | 3.58 | 4.25 | 9 | ||
| 10 | 2.08 | 2.33 | 2.58 | 2.83 | 3.17 | 3.67 | 4.33 | 10 | ||
| eleven | 2.13 | 2.38 | 2.63 | 2.88 | 3.25 | 3.75 | 4.42 | eleven | ||
| 12 | 2.17 | 2.42 | 2.67 | 2.92 | 3.33 | 3.83 | 4.20 | 12 | NC | |
| 13 | 2.21 | 2.46 | 2.71 | 2.96 | 3.42 | 3.92 | 4.53 | 13 | ||
| NC | 14 | 2.25 | 2.50 | 2.75 | 3.00 | 3.50 | 4.00 | 4.57 | 14 | |
| fifteen | 2.28 | 2.53 | 2.78 | 3.03 | 3.53 | 4.03 | 4.60 | fifteen | ||
| 16 | 2.30 | 2.55 | 2.81 | 3.06 | 3.56 | 4.06 | 4.64 | 16 | ||
| 17 | 2.33 | 2.58 | 2.84 | 3.08 | 3.59 | 4.09 | 4.67 | 17 | ||
| 18 | 2.36 | 2.61 | 2.87 | 3.11 | 3.62 | 4.12 | 4.71 | 18 | ||
| 19 | 2.39 | 2.63 | 2.90 | 3.14 | 3.66 | 4.15 | ||||
| twenty | 2.41 | 2.66 | 2.93 | 3.17 | 3.69 | 4.18 | ||||
REFERENCES
| Nominal pressure diameter in SC (mm) | Nominal pressure diameter in SC (mm) | 6 | 10 | fifteen | twenty | 25 | 30 |
| 1.25 | NA | 0067001 | 0067002 | 0067003 | NA | NA | NA |
| 1.50 | NA | 0067101 | 0068102 | 0067103 | NA | NA | NA |
| 2.00 | 2.25 | NA | 0067201 | 0067202 | 0067203 | 0067204 | 0067205 |
| 2.25 | 2.50 | NA | 0067221 | 0067222 | 0067223 | 0063280 | 0067225 |
| 2.50 | 2.75 | NA | 0067251 | 0067252 | 0067253 | 0063310 | 0067255 |
| 2.75 | 3.00 | 0067271 | 0067272 | 0067273 | 0067274 | 0063360 | 0067276 |
| 3.00 | 3.50 | 0067301 | 0067302 | 0067303 | 0067304 | 0063410 | 0067306 |
| 3.50 | 4.00 | 0067351 | 0067352 | 0067353 | 0067354 | 0067355 | 0067356 |
| 4.00 | 4.50 | 0067401 | 0067402 | 0067403 | NA | NA | NA |
